Diamond saw blades speed and cutting depth

Dry Type: Dry type can reach the ideal effectiveness without water. Dry type accelerates cooling for cutting when producing the air streem in rotary motion. It is applied for angle grinders, hand tools, electric tools, etc.
Wet Type: Wet type is designed for operation with water in abundant supply which helps chip removal, cooling, keeping cutting high-speed, extend working life, and good fineness.
Outer
Diameter(mm)
The use of speed (rpm)
Maximum speed(rpm)
105(4")907215000
101(4 1/2")833813897
115(4 1/2")806813300
125(5")725712000
150(6")604810185
180(7")51488730
200(8")45367640
200(8")40326790
250(10")36296115
300(12")30245095
350(14")25924365
400(16")22683820
450(18")20163395
500(20")18143055
600(24")15122550
700(28")13962350
800(32")12102040
900(36")10081700
1000(28")8641455
1200(48")7561257
1400(56")6441092
1600(64")563955

Diameter(mm)Maxinum cutting depth(mm)
350105
400130
500180
600225
700270
800310
900365
1000400
1200500


 TYPE OF EQUIPMENT

Flat sawGrooving sawWalk behind
saw low hp
Floor grinderHigh speed
power saw
Masonry saw
Core drilling
            machine
Hand drillAngle grinder
Circular sawStone sawTile saw

 SAFETY RECOMMENDATIONS
SEGMENT








Different arbor size and segment specification are available upon request!
